沼氣提純的PSA（變壓吸附）工藝詳細步驟如下：

　　The detailed steps of PSA (pressure swing adsorption) process for biogas purification are as follows:

　　一、預處理階段

　　1、 Preprocessing stage

　　脫水處理

　　Dehydration treatment

　　通過冷凝或吸附去除沼氣中的水分，防止吸附劑因吸濕失效。

　　Remove moisture from biogas through condensation or adsorption to prevent adsorbent failure due to moisture absorption.

　　脫硫處理

　　Desulfurization treatment

　　使用活性炭或化學洗滌劑吸附并去除硫化氫（H?S），保護吸附劑活性。

　　Use activated carbon or chemical detergents to adsorb and remove hydrogen sulfide (H2S), protecting the activity of the adsorbent.

　　二、PSA主系統操作

　　2、 PSA main system operation

　　吸附階段

　　Adsorption stage

　　在高壓（0.3-1.0 MPa）下，沼氣通過多塔并聯吸附塔，CO?和H?S被吸附劑選擇性吸附，甲烷（CH?）從塔頂排出。

　　Under high pressure (0.3-1.0 MPa), biogas passes through multiple parallel adsorption towers, where CO? And H? S are selectively adsorbed by the adsorbent, and methane (CH?) is discharged from the top of the tower.

　　減壓與解吸

　　Decompression and desorption

　　降低壓力，吸附的雜質（如CO?）解吸并回收利用或排放。

　　Reduce pressure, desorb and recycle adsorbed impurities (such as CO?) or discharge them.

　　沖洗與再生

　　Rinse and Regeneration

　　用部分產品氣或真空泵逆向沖洗吸附塔，徹底脫附殘留雜質，實現吸附劑再生。

　　Use partial product gas or vacuum pump to reverse wash the adsorption tower, thoroughly desorb residual impurities, and achieve adsorbent regeneration.

　　均壓與沖壓

　　Pressure equalization and stamping

　　完成吸附的塔與沖洗后的塔進行均壓（回收部分產品氣），然后用產品氣沖壓床層，重新充至吸附壓力，準備下一循環。

　　The tower that has completed adsorption and the tower that has been flushed are pressurized evenly (to recover some product gas), and then the bed is flushed with product gas and refilled to adsorption pressure to prepare for the next cycle.

　　三、后處理階段

　　3、 Post processing stage

　　甲烷分離 ：提純后的甲烷氣體壓縮或直接并入管網。

　　Methane separation: The purified methane gas is compressed or directly incorporated into the pipeline network.

　　副產物處理 ：解吸的CO?可回收利用或安全排放。

　　By product treatment: The desorbed CO can be recycled or safely discharged.

　　四、關鍵參數控制

　　4、 Key parameter control

　　吸附劑選擇 ：常用活性炭、沸石分子篩或復合吸附劑，根據雜質類型和純度需求優化。

　　Adsorbent selection: commonly used activated carbon, zeolite molecular sieve or composite adsorbent, optimized according to impurity type and purity requirements.

　　操作壓力 ：根據吸附劑特性調整，通常在0.3-1.0 MPa范圍內。

　　Operating pressure: Adjust according to the characteristics of the adsorbent, usually within the range of 0.3-1.0 MPa.

　　通過以上步驟，PSA工藝能夠高效分離沼氣中的雜質，實現甲烷的高純度提純，適用于中大型沼氣項目。

　　Through the above steps, the PSA process can efficiently separate impurities from biogas, achieve high-purity purification of methane, and is suitable for medium and large-scale biogas projects.

　　沼氣提純的PSA（變壓吸附）工藝詳細步驟如下：

　　The detailed steps of PSA (pressure swing adsorption) process for biogas purification are as follows:

　　一、預處理階段

　　1、 Preprocessing stage

　　脫水處理

　　Dehydration treatment

　　通過冷凝或吸附去除沼氣中的水分，防止吸附劑因吸濕失效。

　　Remove moisture from biogas through condensation or adsorption to prevent adsorbent failure due to moisture absorption.

　　脫硫處理

　　Desulfurization treatment

　　使用活性炭或化學洗滌劑吸附并去除硫化氫（H?S），保護吸附劑活性。

　　Use activated carbon or chemical detergents to adsorb and remove hydrogen sulfide (H2S), protecting the activity of the adsorbent.

　　二、PSA主系統操作

　　2、 PSA main system operation

　　吸附階段

　　Adsorption stage

　　在高壓（0.3-1.0 MPa）下，沼氣通過多塔并聯吸附塔，CO?和H?S被吸附劑選擇性吸附，甲烷（CH?）從塔頂排出。

　　Under high pressure (0.3-1.0 MPa), biogas passes through multiple parallel adsorption towers, where CO? And H? S are selectively adsorbed by the adsorbent, and methane (CH?) is discharged from the top of the tower.

　　減壓與解吸

　　Decompression and desorption

　　降低壓力，吸附的雜質（如CO?）解吸并回收利用或排放。

　　Reduce pressure, desorb and recycle adsorbed impurities (such as CO?) or discharge them.

　　沖洗與再生

　　Rinse and Regeneration

　　用部分產品氣或真空泵逆向沖洗吸附塔，徹底脫附殘留雜質，實現吸附劑再生。

　　Use partial product gas or vacuum pump to reverse wash the adsorption tower, thoroughly desorb residual impurities, and achieve adsorbent regeneration.

　　均壓與沖壓

　　Pressure equalization and stamping

　　完成吸附的塔與沖洗后的塔進行均壓（回收部分產品氣），然后用產品氣沖壓床層，重新充至吸附壓力，準備下一循環。

　　The tower that has completed adsorption and the tower that has been flushed are pressurized evenly (to recover some product gas), and then the bed is flushed with product gas and refilled to adsorption pressure to prepare for the next cycle.

　　三、后處理階段

　　3、 Post processing stage

　　甲烷分離 ：提純后的甲烷氣體壓縮或直接并入管網。

　　Methane separation: The purified methane gas is compressed or directly incorporated into the pipeline network.

　　副產物處理 ：解吸的CO?可回收利用或安全排放。

　　By product treatment: The desorbed CO can be recycled or safely discharged.

　　四、關鍵參數控制

　　4、 Key parameter control

　　吸附劑選擇 ：常用活性炭、沸石分子篩或復合吸附劑，根據雜質類型和純度需求優化。

　　Adsorbent selection: commonly used activated carbon, zeolite molecular sieve or composite adsorbent, optimized according to impurity type and purity requirements.

　　操作壓力 ：根據吸附劑特性調整，通常在0.3-1.0 MPa范圍內。

　　Operating pressure: Adjust according to the characteristics of the adsorbent, usually within the range of 0.3-1.0 MPa.

　　通過以上步驟，PSA工藝能夠高效分離沼氣中的雜質，實現甲烷的高純度提純，適用于中大型沼氣項目。

　　Through the above steps, the PSA process can efficiently separate impurities from biogas, achieve high-purity purification of methane, and is suitable for medium and large-scale biogas projects.
